SETUP
Package Inspection
The D series colorant dispenser has been carefully inspected and calibrated to measure colorant with a high
degree of accuracy. It should be carefully examined upon arrival to determine that the unit shows no signs
of shipping damage. If any parts are found to be broken or damaged, immediately contact the carrier and
arrange for an inspection of the concealed damage. Claims for damage must be made by you, the
consignee, and not the shipper. The carrier accepts full responsibility for the safe delivery of merchandise
upon pick-up from the shipper.
 Check the contents as you unpack and if any parts are missing, contact your supplier or HERO
Products Group as soon as possible.
 Do not commence set-up until all required parts are available.
Package Contents – Counter Top Models
 Turntable
 Drive Plate Assembly
 Drive Cover
 Countertop Stand with attached pre-lubricated crankshaft and washer
 Canisters with calibrated gauges
 Bag containing canister mounting hardware
 Envelop which contained this manual, plus “Lettering”
 Bag containing spare parts
• Three nozzle o-rings
• Three spare nozzles (1 each of S, L & XL)
 Replacement seal and installation tool
Package Contents – Floor Stand Models
Floor stand models include all of the items from a counter top model plus the following:
 Floor stand
 Support legs with mounting hardware
 Adjustable tray
 Bag containing floor stand to countertop stand mounting hardware
