Dispensing
1. With the gauge correctly set, slowly and gently lift the plunger handle until it reaches the gauge
knob.
2. Continue to hold for a few seconds to ensure that the cylinder has completely filled with colorant.
NOTE: Do not open or operate the valve while charging the cylinder or air will enters the system and result
in an inaccurate dispense.
3. With the plunger at the top and the cylinder full, pull the spring loaded valve handle downwards
until it stops and hold in that position.
4. With the opposite hand, push the plunger down completely until it rests on the end cap.
5. Release the valve handle and allow it to return to the closed position.
6. Repeat the dispensing procedure as necessary to complete the formula.
7. Once all required colorants have been dispensed, gently lower the gauges manually to their zero
position.
NOTE: Do not allow the gauges to drop down as doing so can damage them and result in dispensing
inaccuracy.
