HERO Passion Pro - DESCRIPTION AND PARTS LOCATION; Front View Parts Identification

1
5
7
11
(2) Turn signal switch
(5) Passing switch
(6) Rear view mirror
(7) Dimmer switch
(4) Headlamp switch
(9) Neutral indicator
(10) High beam indicator
(11) Speedometer
(3) Clutch lever
(1) Horn switch
(8) Side stand indicator
(12) Turn signal indicator
(16) Front brake lever
(17) Throttle grip
(18) Electric starter switch
(14) Reset button
(21) Leg guard
(19) Ignition switch with steering lock
(13) LCD panel
(15) Master cylinder
(20) Fuel tank cap
141312
8 9
10
4
6
16
17
18
19
20
21
3
15
2
DESCRIPTION
