15
(1) Seat Lock (2) Knob (3) Helmet Hanger
1
3
For the safety of the customer a side stand
indicator (1) is provided.
When the vehicle is parked on side stand
(Ignition Switch “ON”), an indicator lamp
glows in the speedometer panel.
SIDE STAND INDICATOR
Operation : Insert the key and turn it
clockwise. Pull the knob (2) downwards
to release the seat. To install, engage the
hook on the underside of the seat with the
frame and push on the top rear side of the
seat until the lock (1) clicks.
Helmet Hanger
The helmet can be hung and locked on the
hook provided with the seat lock (1) by
rotating the key.
SIDE STAND SWITCH
A side stand switch (2) is provided in the
side stand, when the vehicle is parked on
side stand (Ignition Switch “ON”), the
switch enables the side stand indicator
lamp to glow on the speedometer panel.
(2) Side stand switch
(1) Side stand indicator
2
2
1
