16
At “RES” (3), fuel will flow from the
reserve fuel supply to the carburetor. Use
the reserve fuel only when the main supply
is exhausted. Refill the tank as soon as
possible after switching to “RES”. The
reserve fuel supply is 1.0 litre (usable).
FUEL VALVE
1
FUEL
ON
OFF
RES
2
FUEL
ON
OFF
3
FUEL
OFF
RES
(1) “OFF” Position
(2) “ON” Position
(3) “RES” Position
At “ON” (2), fuel will flow from fuel tank
to the carburetor
ON
OFF
At “OFF” (1), fuel cannot flow from the
tank to the carburetor. Turn the valve
“OFF” whenever the motorcycle is not in
use.
