17
motorcycle
(1) Key hole cover (2) Fuel tank cap
(3) Ignition key
3
2
FUEL TANK
2. Do not overfill the tank. There should be
no fuel (3) in the filler neck (4).
1. To remove the fuel tank cap (2), open
the key hole cover (1) and insert the
ignition key (3) turn it clockwise and
remove the cap.
Fuel tank capacity is 12.8 litres including a
reserve supply of 1.0 litre (usable).
3. For locking, position the cap back on the
opening and press gently. The key
springs back to the normal position and
the cap gets locked.
NOTE
Do not park the motorcycle under direct
sunlight as it causes evaporation of petrol
due to heat and deterioration of paint gloss
due to ultra violet rays.
1
