Shift the turn signal knob sideways for
right/left indications and leave it to come
back to its normal position on its own.
5
4
IMPORTANT : To switch OFF the turn
signal after completing the turn, gently
push inside.
1
2
white
Functions in DC when the passing switch
knob is pressed in the following condition.
1. Headlamp switch is “OFF”.
2. Headlamp switch is “ON” but on low beam.
3
13
LEFT HANDLEBAR CONTROLS
Passing switch
Dimmer switch
Headlamp switch
4. Turn signal lamp switch
5. Horn switch
Tail/Stop lamp
Headlamp “ON”
Speedometer L.E.D.
After getting the vehicle serviced, make
sure that the Service Reminder Indicator
has been reset.
NOTE
6
