HERO Passion Pro - CLUTCH AND DRIVE CHAIN MAINTENANCE; Clutch Cable Checks; Drive Chain Inspection and Lubrication

39
B
A
If proper adjustment cannot be obtained or
the clutch does not work correctly, visit your
Authorised Hero MotoCorp Workshop.
Drive chain slack (3) should be adjusted
to allow approximately 25 mm (1 inch)
vertical movement by hand.
1
22
3
4
Turn the engine “OFF”, park the
motorcycle on its main stand and shift
the transmission to neutral. Remove
hole cap (2).
Clutch cable
adjusting nut
