: 5.4 kgf-m
8
56
(Cast wheel version)
Remove the axle nut (8) and pull out the
rear axle (9). Remove the wheel.
Adjust the brake (page 45) and drive
chain (pages 39 to 42).
Brake stopper arm nut torque : 2.2 kgf-m
Always replace used split pins with new ones.
9
Remove the rear brake adjusting nut (1)
and disconnect the brake rod (2) from the
brake arm (3) by pushing down the brake
pedal. Disconnect the brake stopper arm
(4) from the brake panel (5) by removing
split pin (6) and lock nut (7).
(9) Rear axle
Lock nut
Brake stopper arm
3
1
7
