H8 DSP
Digital Interface Processor
User’s manual
AUXILIARY STEREO
PREAMPLIFIER SOURCE
AUXILIARY STEREO
PREAMPLIFIER SOURCE
MP3 PLAYER
PRE OUT
RADIO DECK
5
TOSLINK
CONNECTOR
OPTICAL CABLE
12
5.5 LOW-LEVEL INPUT SIGNALS
5.6 OPTICAL IN DIGITAL INPUT
AUX IN L/R: Auxiliary analog stereo signal.
Sensitivity is adjustable from 0.6 to 5 V RMS
DIGITAL INPUT- WARNING: the digital input accepts up to
96 kHz / 24 bit stereo PCM signals. So DOLBY
DIGITAL (AC3) multi-channel signals coming from
audio/video sources (such as the audio of a film
in DVD) or DTS can not be reproduced. The output
of these devices will therefore be set in STEREO
mode for the signal to be reproduced. If digital
signals at frequency higher than 96kHz (Ex. 192 kHz)
are supplied, the H8 DSP locks up.
