H8 DSP
Digital Interface Processor
User’s manual
1/2
- Quick start guide
3
WARNING: 1- To Install the software and set up the H8 DSP a PC provided with Windows XP, Windows Vista, Windows 7,
Windows 8 or Windows 10 operating system, 1.5 GHz minimum processor speed, 1 GB RAM minimum
memory and a graphics card with a minimum resolution of 1024 x 600 pixels is required.
2- Before connecting the H8 DSP, carefully read this manual. Improper connections may cause damage to the
H8 DSP or to the speakers in the car audio system.
1. PRODUCT DESCRIPTION / SAFETY PRECAUTIONS
The H8 DSP is a digital signal processor essential to maximize the acoustic performance of your car audio system. It
consists of a 32-bit DSP processor and 24-bit AD and DA converters.
It can connect to any factory system, even in vehicles featuring an integrated audio processor, since, thanks to the
de-equalization function, the H8 DSP will provide a linear signal.
It features 7 signal inputs: 4 Hi-Level, 1 Aux Stereo, 1 S/PDIF optical digital and It provides 8 PRE OUT.
Each output channel has a 31-band equalizer available. It also features a 66-frequency electronic crossover as well as
BUTTERWORTH or LINKWITZ filters with 6-24 dB slopes and a digital time delay line. The user can select adjustments
that allow him or her to interact with the H8 DSP through a remote control device called DRC.
2. PACKAGING CONTENTS
- H8 DSP - Signal Interface Processor
- Power supply cable / Remote / Inputs
- 3.0 m / 9,84 ft USB cable
- 4 of 3.5 x 13 mm / 0,13” x 0,51”
self-tapping, cross-head fixing screws
- CD ROM with:
• H8 DSP Software
• This advanced manual
(.pdf format) Test tracks
