H8 DSP
Digital Interface Processor
User’s manual
8.6 “CONFIG” MAIN MENU
3
1
2
3
4
5
6
8
32
If you click on the Config tab, a drop-down menu appears listing the entries shown in the
image on the right:
1. I/O Configuration Wizard: it enables the system calibration and allowing the H8 DSP to
function in the required conditions
(see 8.1.5).
2. Working Mode - Standard / Expert: the software can work in two modes, acting on the
crossover filter.
• Standard: simplified mode with some restrictions easing the use of the software
(see 8.10).
• Expert: no restrictions to the use of the software (see 8.10). We suggest to try and use the
software in Expert mode; if it is too difficult, change to Standard mode.
WARNING: When you change from one mode to the other, the filters are restored
to their defaults
3. Current Input Type: it displays the specialization assigned to the MASTER inputs.
4. Start up/Shutdown delays: it enables the modification of the H8 DSP turn on / off
time settings
• StartUp Time: delay between turning the device on and audio output activation. Every
amplifier exhibits, while turning on, its own delay before being operational. If you set
Startup Time to a value higher than or equal to the longest of these delays, the entire
audio system will be synchronized.
• Shutdown time: delay between turning the REMOTE OUT signal off for the amplifiers
and turning the H8 DSP off. It is generally not necessary to change this parameter, but
can be decreased if your amplifiers produce a “Bump” when shut down
5. External Source: : it provides the ability to enable or disable auxiliary sources selected or
left out during the I/O configuration Wizard
(see 8.1.6).
6. Help: when activated by selecting “Active”, it enables the display of context messages
regarding the software section in use. Different languages connected to the context
messages can be selected from a drop-down menu.
E.g.: Help
