Technical Data
Operating Voltage
12 to 24 Volts AC or DC
Set point Setting Range
5-35 oC in 0.1 oC Increments
Relay Switch ON Points
(Dead band)
0.1-19.9 oC
Relay Hysteresis
(Switching Differential)
0.1-9.9 oC
Relay to Energise Time Delay
0.1-42 Minutes
General Specifications
200mA
At 24vDC Volts
At 24vAC Volts
5 VA
Power Consumption
Voltage AC 0….250 Volts
Current
8.0 (2.5) Amps
Switching Capacity of Relays
Y1/Y2 Output Voltage Range 0-10VDC
Y1/Y2 Start Point (Dead band) 0-19.9 oC
0.5-25 oC
Output Indication
Relay On/Off Status
LCD Display
Display Resolution
5 x Red LED
2 x 16 character LCD
0.1 Increments
Y1/Y2 Range
(Proportional Band)
Y1/Y2 Integral action
(P+I triggers >10% P output)
Off-60 minutes
Communication :
Terminal's X5 & X6 configurable as RS485 MODBUS Outputs
X7 can be set to ground (via a 100 ohm resistor) for use as a
comms shield connection if not used as a CO2 sensor connection.
ANALOG INPUTS
X1 : Main Temperature Sensor Input configurable (with jumper & software) as
Active (0-10vdc ~0 to 100c (adjustable) or Passive (4.2k@22c).
X2 : Remote Set point configurable (with jumper & software) as
passive using 10K
Potentiometer (18-25c Range) or 0-10vdc (top end range configurable).
X3 : Outside temperature sensor configurable (with jumper & software) as Active
(0-10v~0-100c) or Passive (4.2k@22c).
X4 : Auxiliary Measurement Temperature Sensor, Input configurable (with jumper)
as Active (0-10vdc ~0 to 100c (adjustable) or Passive (4.2k@22c).
X7 : Room or R/A Duct CO2 Sensor input to override economy cycle operation or
to control internal relays (R1-4) not used for temperature control.
HEVAC Control Agencies Pty Ltd www.hevac.com.au Ph +613 95627888
28/11/19
( NOTE MINIMUM & MAXIMUM Y OUTPUT VOLTAGE USER ADJUSTABLE )
