PROGRAM
MENUS
HEVAC Control Agencies Pty Ltd
www.hevac.com.au Ph +613 95627888 28/11/19
7/28
MENU
Set CLOCK :
Set "START BY " METHOD :
TO SET THE CONTROLLERS TIME, DATE AND ENABLE DAY LIGHT SAVING
SET SYSTEM ON/OFF OPERATION "BY" the internal TIMESWITCH (1), Internal RUN
TIMER (Triggered by remote push button) or by a remote MANUAL ON / OFF SYSTEM
SWITCH (by shorting out sensor X1 & M wires or D1 & M terminals).
SET MAIN TIME SWITCH (1) :
PROGRAM MAIN (SYSTEM) TIME SWITCH (1) DAYS & ON OFF TIMES .
SET AUX. TIME SWITCH (2) : PROGRAM AUXILIARY INDEPENDENT 7 DAY TIME SWITCH (2) ON & OFF TIMES.
SET RUN / AHR TIMER PERIOD : SET RUN TIMER DURATION FOR USE AS AN AFTER HOURS RUN TIMER OR AS A
SYSTEM RUN (FOR) TIMER ( with or without use of the main time switch ).
SET HOLIDAYS : PROGRAM INDIVIDULE OR GROUP HOLIDAYS SYSTEM OFF OVERRIDE DATES.
VIEW EVENT HISTORY : VIEW "ON" EVENT HISTORY - DATE , TIME & EVENT.
R1-4 RELAY PROGRAMMING : SET MODE & SETTINGS FOR THE 4 PROGRAMMABLE RELAYS (R1-4).
R5 FAN CONTROL METHOD : PROGRAM R5 (FAN) TO CYCLE WITH HEAT / COOL CALL OR CONTINUOUS.
Y1 & Y2 ANALOGUE PROGRAMMING :SET MODE & SETTINGS FOR THE 2 PROGRAMMABLE ANALOGUE (Y1 &Y2) O/P's
X1 SENSOR CONFIGURATION :
SET MAIN CONTROL SENSOR (WHICH RELATES TO THE CONTROLLERS SETPOINT)
AS ACTIVE or PASSIVE, CAL OFFSET & RANGE ADJUSTMENT.
X2 REMOTE S/P CONFIGURATION : SET TYPE OF OPTIONALLY CONNECTED REMOTE SETPOINT AS PASSIVE 0-10K
(FIXED RANGE OF 18-25C) or 0-10VDC (MAX RANGE ADJUSTABLE).
X3 O/AIR TEMP. SENSOR CONFIG. : ENABLE & ADJUST SETTINGS FOR O/A TEMPERATURE SENSOR & ITS AFFECTS
X4 SUPPLY AIR SENSOR CONFIG : ENABLE MONITORING (ONLY) OF AN AUX. SENSOR ..ie S/A TEMPERATURE.
X7 CO2 SENSOR CONFIGURATION : ENABLE & ADJUST SETTINGS FOR A ROOM or (R/A DUCT) CO2 SENSOR
FUNCTION
ENABLE NIGHT PURGE :
MODBUS SETUP :
SET CONTROL APPLICATION :
RESTORE FACTORY DEFAULTS :
EXIT MENU :
ENABLE & CONFIGURE TIME AND TEMP. CONDITIONS FOR NIGHT VENT MODE
ENABLE MODBUS & SET BAUD RATE & ADDRESS SETTINGS
SET ENDEAVOUR IN STANDARD TEMPERATURE. or TIME SWITCH ONLY MODE
CLEARS & RESETS ALL SETTINGS BACK TO FACTORY DEFAULTS
EXIT THIS MENU LIST AND RETURN TO OPERATING SCREENS
*
*
*
*
*
*
*
* these menu settings have no affect in TIME SWITCH ONLY application
