Scale Bar Placement Guidance
3. TARGET-FREE SCANNING SETUP
Scale Bar
NOTE:
DO NOT PLACE SCALE BAR OVER
CODED TARGET OR CIRCULAR
POSITIONING TARGET!
Position: Place the scale bar in the
middle of the wall as shown in the
Direction: The scale bar should place as
the arrow indicates direction
One end of the scale bar with direction indicator
Situation 1, To use three walls as
shown in the picture
