Scanner Calibration
4. CALIBRATION
In calibration process, the position and attitude of scanner should be aligned with the corresponding position of each
indicator bar (cross circle is aligned with solid circle, three red indicators are aligned with three green ones
respectively).
Left indicator bar
Right indicator bar
Top indicator bar
