Scanner Calibration
4. CALIBRATION
The scanner must point to the center of the calibration plate, as indicated by the circle, and the red line (the height
and direction of the scanner) should be always in the green area.
1. Right indicator bar: The height of the scanner from the calibration plate, adjusting the height in the direction
perpendicular to the calibration plate
2. Top indicator bar: The horizontal tilt angle of the scanner, tilted left and right
3. Left indicator bar: The vertical tilt angle of the scanner, tilted front and back
4. Arrow: indicates the rotation angle of the scanner around the coordinate axis of the vertical calibration plate.
When scanning, try to ensure that the crosshair does not rotate. The left and upper green indicator bar indicates
the specified tilt angle, and the right green bar indicates the height
5. The Arrow Circle: Indicates the current position of the scanner; the size of the circle indicates current height of
the scanner from the calibration plate
6. The Green Solid Circle: Indicates the specified position where the scanner needs to be aligned
