Target Placement
6. SCANNING PROCESS WITH TARGET
PLEASE DO NOT
• Place targets on a surface with high curvature
• Place targets on obvious features of the workpiece
• Place targets near the edge/detail (< 4mm)
• Use damaged or incomplete targets
• Use greasy, ashy or dirty targets
Tips:
make sure that at least 4 targets can be seen in same vision of
scanner from different angles at all time.
Wrong Example
