Main circuit breaker
brief construction of main circuit breaker
G3 meter cabinet provides three kinds of current level of main circuit breaker.
100A and 200A.
100A circuit breaker
200A circuit breaker
Nameplate construction of main circuit breaker
1
Mounting holes
6
Test button
11
Standard
2
Product name
7
Trademark
12
ON、Trip、OFF
3
Technical Parameters
8
Certification mark
13
QR code
4
Breaking capacity
9
Category
5
Manufacturer name
10
MCCB with isolation
