User manual for G3
59
Wall installation
⚫ Installation Tools: percussion drill with drill head (direct 10mm) , 6"
monkey wrench, pencil.
⚫ Installation Accessories: 2pcs expansion bolts (M10*100), hanger
bracket
⚫ Step / Method
a) According to the bracket distance in below picture, mark hole
positions and distance on the wall. The length (bracket distance refer
to chapter 13.1.4) will be 232mm or 300mm.
