User manual for G3
50
For pole has 300mm distance of preset two installation holes
Installation
Attention before installation
⚫ Make sure all the accessories are complete before installation.
⚫ The meter cabinet should be installed vertically; the inclination angle
should no more than 5°.
⚫ Installation site should be no violent vibration or shock and no corrosion
to electrical element.
⚫ Keep the sharp and hard objects away from the meter cabinet surface
during installation or maintenance.
⚫ Periodically cleaning the cabinet surface is recommended during running
on site.
⚫ Select dry, shady and cool place for meter cabinet installation, to avoid
direct exposure under sunlight for long time, in order to extend the life
circle of the meter.
Pole installation
Pole with preset hole
In Latin American countries like Dominica, Panama, pole always has mounting
