HEXING HXE12-DL - Appearance; Standard

User manual for single-phase meter
2
2 Appearance
No.
Description
1
LCD display
2
Pulse LED(active energy)
3
Nameplate
4
Meter Cover
5
Meter Cover Seal
6
Active Pulse output
7
Terminal block
8
Terminal cover Seal
9
Display button
10
Alarm LED
11
Optical port
3 Standard
Standard
Description
IEC 62052-11
Electricity metering equipment (a.c.)
– General requirements, tests and test conditions
– Part 11: Metering equipment
IEC 62053-21
Electricity metering equipment (a.c.)
–Particular requirements
–Part 21:Static meters for active energy(classes 1 and 2)
