6.6 Turn on Bluetooth again
The bluetooth function of LD2410C is enabled by default, and can be"LD2410C Serial Communication Protocol.pdf"Turn off or turn on Bluetooth. If the
Bluetooth has been turned off, or the serial port cannot be used, power off the module within 2~3 seconds and then power on the module for more than 5 times to
turn on the Bluetooth again.
7 Performance and Electrical Parameters
24GHz~ 24.25GHz
Comply with FCC, CE, non-committee certification standards
Working frequency
power requirements
DC 5V, power supply capacity >200mA
Average working current
79 mA
Modulation
FMCW
One GPIO, IO level 3.3V
a UART
interface
target application
human presence sensing
Detection distance
0.75m〜6m, adjustable
detection angle
±60°
distance resolution 0.75m
250MHz
Comply with FCC, CE, non-committee certification standards
Sweep bandwidth
ambient temperature - 40 ~ 85℃
Dimensions 16mm x 22mm
Table 2 Performance and Electrical Parameters Table
Figure 11 The measured data of the working current of the module
