HLK-LD2420
user manual
HLK-LD2420The specification parameters are shown in the table2-1shown.
parameter Remark the smallest typical maximum unit
hardware specification
Support frequency band twenty four - 24.25 GHz
Comply with FCC, CE, non-committee certification standards
Support maximum sweep bandwidth - 0.25 - GHz
Maximum equivalent isotropic radiated power - 11 - dBm
supply voltage 3.0 3.3 3.6 V
size - 20 x 20 - mm2
ambient temperature - 40 - 85 °C
system performance
Sports Human Target - 8 - m
Distance detection range (wall-mounted)
micro-motion human target - 6 - m
Sports Human Target - 5 - m
Distance detection range (ceiling)
micro-motion human target - 4 - m
Distance Detection Accuracy Moving targets within 8m of the straight-line distance from the radar - ±0.35 - m
Average working current - 50 - mA
data refresh rate - 10 - Hz
3total pages15Page
