Introduction of hardware
Fig.1.1-4
Fig.1.1-5
5-core socket and 8-core socket
1
1
2
2
3
3
4
4
5
5
6
7
8
3. Transceiver antenna port: Used to connect internal transceiver antenna for receiving and
transmitting differential signal.
Cautions:
1. when 8-core socket or 5-core socket is not in use, please cover them with the plug.
2. When water enters into the trumpet, it is likely that the trumpet is silent or hoarse.The voice can
recover after the trumpet is dry.
