INSTALLATION GUIDE
iCLASS SE/multiCLASS SE PLT-01579 A.4
R10E, RP10E, R15E, RP15E, R40E, RP40E, RK40E, RPK40E, R10MA, RP10MA, RP15MA, R40MA, RP40MA, RPK40MA
Regulatory
The final product, containing the modular transmitter must be labeled with its own FCC ID and IC ID. If the FCC & IC ID is not visible, when the module is installed inside another
device, then the final assembly label must contain the FCC and IC ID numbers with a statement such as follows: “Contains Transmitter Module with FCC ID JQ6-ICLASSBTM and IC ID
2236B-ICLASSBTM”.
UL
Connect only to a Listed Access Control / Burglary power-limited power supply. These readers are intended to be used with listed (UL294) control equipment. Suitable for outdoor use.
Only Wiegand and RS-485 communications have been evaluated by UL.
FCC
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.
CAUTION: Any changes or modifcations to this device not explicitly approved by the manufacturer could void your authority to operate this equipment.
Indala Prox products RP10EL, RP15EL, RP30EL, RP40EL and RPK40EL are certified for FCC, Canada Radio Certification and CE Marking only.
Canada Radio Certification
This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2)
this device must accept any interference, including interference that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes
: (1) l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en
compromettre le fonctionnement.
CE Marking
HID Global hereby declares that these proximity readers are in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC.
Por el presente, HID Global declara que estos lectores de proximidad cumplen con los requisitos esenciales y otras disposiciones relevantes de la Directiva 1999/5/EC.
HID Global déclare par la présente que ces lecteurs à proximité sont conformes aux exigences essentielles et aux autres stipulations pertinentes de la Directive 1999/5/CE.
A HID Global, por meio deste, declara que estes leitores de proximidade estão em conformidade com as exigências essenciais e outras condições da diretiva 1999/5/EC.
HID Global bestätigt hiermit, dass die Leser die wesentlichen Anforderungen und anderen relevanten Bestimmungen der Richtlinie 1999/5/EG erfüllen.
HID Global dichiara che i lettori di prossimità sono conformi ai requisiti essenziali e ad altre misure rilevanti come previsto dalla Direttiva europea 1999/5/EC.
Download copies of the R&TTE Declaration of Conformity (DoC) at http://www.hidglobal.com/certifications.
Taiwan
According to “Administrative Regulations on Low Power Radio Waves Radiated Devices” Without permission granted by the NCC, any company, enterprise, or user is not allowed
to change frequency, enhance transmitting power or alter original characteristic as well as performance to a approved low power radio-frequency devices. The low power radio-
frequency devices shall not influence aircraft security and interfere legal communications; If found, the user shall cease operating immediately until no interference is achieved. The
said legal communications means radio communications is operated in compliance with the Telecommunications Act. The low power radio-frequency devices must be susceptible
with the interference from legal communications or ISM radio wave radiated devices.
Japan MIC UAE Singapore
“ この装置は総務省の型式指定を受けています。”
(総務省指定番号は第AC-ｘｘｘｘｘ号です)
本製品は電波を使用したRFID 機器の読み取り・書き込み装置です。
そのため使用する用途・場所によっては、医療機器に影響を与える恐
れがあります
TRA
REGISTERED NO:
nnnnnnn
DEALER NO:
DA37204/14
Complies with
IDA Standards
DA103548
Korean KCC
R10E, R15E,
R30E,R40E, RK40E
RP10E, RP15E,
RP30E, RP40E, RPK40E
Mobile Ready
R10MA, RK40MA RP10MA
항목 규격 규격
송신주파수 RFID:13.56MHz RFID:13.5607MHz,
LPD:125KHz
RFID:13.56MHz
RFID:2.40-2.48GHz
RFID:13.56MHz
RFID:2.40-2.48GHz
LPD:125KHz
수신주파수 RFID:13.56MHz RFID:13.56MHz,
LPD:125KHz
RFID:13.56MHz
RFID:2.40-2.48GHz
RFID:13.56MHz
RFID:2.40-2.48GHz
LPD:125KHz
출력 RFID:10m에서
47.544mv이하
RFID:10m에서47.544mv이하.
LPD:3m거리에서500㎶/m이하
HFRFID:10m에서3108.1㎶/m
BLERFID:10m에서EIRP-3.9dBm/1MHz
LFRFID:10m에서31.6㎶/m
HFRFID:10m에서498.9㎶/m
BLERFID:10m에서EIRP-3.9dBm/1MHz
전원 DC16.0V DC16.0V
전파형식 A1D A1D
발진방식 X-tal
X-tal(13.56MHz)Resonator(125kHz) X-tal(13.56MHz&2.4GHz) X-tal(13.56MHz&2.4GHz)
Resonator(125kHz)
변조방식 ASK ASK(13.56MHz),FSK(125kHz) HF:ASK,BLE:GFSK LF:FSK,HF:ASK,BLE:GFSK
Israel (Mobile Ready RP10)
השימוש במכשיר הינו על בסיס "משני" ופטור מרשיון הפעלה אלחוטי.
רק "בפעולת בזק" לשימוש עצמי של הלקוח בלבד, הלקוח פטור מרשיון הפעלה אלחוטי.
אסור להחליף את האנטנה המקורית של המכשיר, ולא לעשות בו כל שינוי טכני אחר.
Russia
Дата изготовления указана на маркировке оборудования
Представитель в Российской Федерации
Название ООО «Дофин» Телефон +7 495 223 6008
Адрес 140573, РФ, Московская обл., Озерский район, с. Бояркино e-mail local.declarant@gmail.com
Контактное лицо Л.Н. Голубова
