Page 18 of 26 Installation Guide
© 2018 HID Global Corporation All rights reserved.
Web-Based Access Control Solution
ACW2-XN
9 Electrical Specifications
Power Supply (A-X1)
AC Mains Input
100-230 VAC (50/60Hz), 1.3A 12V, 5A
Optional Battery (Strongly recommended)
Not included with the ACW2-XN, this battery must be sourced separately
Note:
• Only connect the battery after all system wiring is complete and tested on the built-in power
supply
Battery Specification
Type Lead Gel
Voltage 12V
Capacity 7 Ah
Physical Dimensions
65 mm x 101 mm x 151 mm,
2.56” x 3.98” x 5.95” – or smaller
Specification
Length 20 mm, 0.787”
Type Slow-blow
Rating 6.3 A
Controller Module (AC)
Power
Conditions Current Power
Supply at 12V DC 140 mA 1.7 W
Inter-Module Communications
Connector Purpose
female on the left,
male on the right
Power and data lines to other
modules
Network
Connector Protocol
RJ45
Ethernet, 10/100 Base T, half or full
duplex
