HID EDGE EVO EH400 - Analyze Power Requirements; Door Peripheral Operational Currents; Match I;O Requirements to Hi-O Interface

82000-920, D.1
INSTALLATION GUIDE 3
©2009 - 2012 HID Global Corporation. All rights reserved.
EDGE EVO Hi-O Networked Controller
EH400
Step 3 - Analyze Power Requirements
A - Door Peripheral Operational Currents
For the door peripherals identied in “Step 1 - Identify System Components” on page 2, consult the vendor data
sheets to determine the operational current draw. Typical operational current draw is provided below.
Note: See individual peripheral data sheets for actual operational current draw.
Device Conditions Typical Operational Current
Door Position Switch Vin = 12VDC 15mA
(For example, Securitron MSS) Vin = 24VDC 15mA
Mag Lock Vin = 12VDC 300mA
(For example, Securitron M32) Vin = 24VDC 150mA
REX Switch Vin = 12VDC 28mA
(For example, Securitron EEB) Vin = 24VDC 38mA
Exit Alarm
(For example, Detex 411)
Vin = 12VDC
Vin = 24VDC
70mA
70mA
iCLASS Wiegand Reader Vin = 12VDC 150mA
Consult HID datasheets for Hi-O enabled interface devices.
B - Match I/O Requirements to the Hi-O Interface Device
For the door peripherals identied in “Step 1 - Identify System Components” on page 2, the system requires
connection to a Hi-O interface device. In this example, the EDGE EVO Hi-O Edge Door Module (EDM-M) provides
general purpose I/O connectivity.
The Hi-O iCLASS reader does not require connection to the EDM-M and derives power and data connectivity from the
Hi-O CANbus directly.
Device Ports Conditions I out
EDGE EVO Hi-O Door
Module EDM-M
Strike / Aux
NC or NO
DC Output
+12VDC unregulated (@+12VDC EDM-M input) 700mA*
+24VDC unregulated (@+24VDC EDM-M input) 700mA*
+12VDC regulated (@+24VDC EDM-M input) 310 mA*
Dry Jumpers
+12 to +24VDC External 2.00 Amp**
* Shared between each relay
** Each relay
The combined current requirement for the four door peripherals identied in “Step 1 - Identify System Components” on
page 2 is 413mA @ +12VDC,
or 273mA @ +24VDC.
The EDM-M provides sufcient power when the door peripherals are connected to the Strike/AUX relays congured for
unregulated output at +12VDC/+24VDC. Alternatively, connect the door peripherals to the Strike/AUX relays congured
for Dry contact.
The Hi-O iCLASS reader does not require connection to the EDM-M and derives power and data connectivity from the
Hi-O CANbus directly.
