Drive shaft and lower case
Drive shaft and lower case
No. Part name Q’ty Remarks
1Drive shaft 1
2 Clip 1
3 Oil seal 2
4 Bushing 1
/PUSFVTBCMF
/PUSFVTBCMF
/PUSFVTBCMF
5 Lower case 1
6 Bushing 1
/PUSFVTBCMF
7 Washer 1
8 Pinion 1
9 E-clip 1
10 Ball bearing 1
/PUSFVTBCMF
11 Forward gear 1
1
2
3
4
5
6
7
8
9
10
11
Propeller shaft housing / Drive shaft and lower case
