Hidea HDF6 - Intake Silencer

Intake silencer
Intake silencer
No. Part name Q’ty Remarks
1Hose 1
2Hose 1
3Bolt 1
4 Washer 1
5 Collar 1
6 Throttle cam 1
7Lever 1
8 Holder 1
9 Clamp 3
10 Gasket 1
/PUSFVTBCMF
11 Throttle link rod 1
12 Intake manifold bolt 2
13 Intake manifold 1
14 Gasket 2
/PUSFVTBCMF
15 Spacer 1
16 Cap 1
17 Hose 1
21
20
20
17
16
11
10
2
9
3
4
5
6
7
8
14
15
14
13
12
18
9
9
21
22
19
23
1
12 N·m (1.2 kgf·m, 8.9 ft·lb)
Fuel tank / Intake silencer
77
