Technical features and description
Engine control systemOutline
The F6 adopt the CDI ignition system consisting of the CDI unit and the flywheel magnet.
The CDI unit has a compact design with an integrated ignition coil.
There are two types of ignition control systems. One is ignition timing control at normal operation,
and the other one is ignition cut-off control during engine cranking and when over-revving.
aCDI unit
bFlywheel magnet
a
b
30
