Hidea HDF6 - Page 191

General periodic maintenance
6. Install a new gasket f and the check
scr
ew d.
7. Remove the gear oil tube, and then
install a new gasket g and the drain
screw b.
8. Tighten the check screw d and drain
screw b to the specified torque.
Checking the gear oil level
1. Check the gear oil level. See “Checking
the gear oil level”.
Checking the ignition timing
1. Check the ignition timing. See “Checking
the ignition timing”.
Lubricating the outboard motor
1. Apply water resistant grease to the spec-
ified areas.
Oil quantity:
0.1 L
Check screw d:
9 N·m (0.9 kgf·m, 6.6 ft·lb)
Drain screw b:
9 N·m (0.9 kgf·m, 6.6 ft·lb)
d
f
g
b
191
