2. Wiring and connection
2-16
3
4
5
6
7 BAT+ 3 K
8 BAT- 4 L
9 GND 6 G
10
11
F.G. 7 N
12
Shield 8 J
13
14
15
16
17
18
19 Vcc( DC 5V ) 5 H
20
♥ Connect the grounding wire of the encoder wiring cable for F.G
♥ Applied cable specification: AWG24 x 5Pair TWIST,SHIELD CABLE (Maximum length 20m)
