Hikmicro THUNDER User Manual

Thermal Image Scope User Manual
27
Chapter 13 Appendix
13.1 Device Command
Scan the following QR code to get device common serial port commands.
Note that the command list contains the commonly used serial port commands for Hikmicro
thermal cameras.
13.2 Device Communication Matrix
Scan the following QR code to get device communication matrix.
Note that the matrix contains all communication ports of Hikmicro thermal cameras.

Hikmicro THUNDER Specifications

General

Pixel Pitch	12 μm
Frame Rate	50 Hz
Aperture	F1.0
Record Video	Yes
Capture Snapshot	Yes
Wi-Fi	Yes
Display	0.39" OLED
Magnification	1x
Response Waveband	8 μm to 14 μm
Lens (Focal Length)	19mm
Battery Type	Rechargeable Li-ion
Power Supply	DC 5V/2A
Operating Temperature	-20°C to +50°C
Reticle	Yes
Storage Temperature	-30 °C to 60 °C (-22 °F to 140 °F)
