HIKVISION 7604NI-K1B Quick Start Guide

Network Video Recorder Quick Start Guide
22
Chapter 3 Menu Operation
3.1 Menu Structure
Refer to the following figure for the menu structure:
Menu
Export
Manual
HDD Camera
Maintenance
Shutdown
Record
Configuration
Playback
Normal
Record
General
Schedule Camera General
System Info
Logout
Event
Advanced
Parameters OSD
Network
Log
Information
Shutdown
Advanced
Import/
Export
Reboot
Holiday PTZ
Upgrade
Motion
Live View Default
Privacy
Mask
Exceptions
Net Detect
Video
Tampering
User
Video Loss
HDD Detect
Alarm
Continuous
Capture
RS-232
VCA
Normal
Event
Tag
Sub-periods
External
File
VCA Search
Behavior
Search
Face Search
Counting
Heat Map
Alarm
Hot Spare
Plate
Search
Figure 3. 1 Menu Structure
The menu structure may vary according to different models.
3.2 Startup and Shutdown
Proper startup and shutdown procedures are crucial to expanding the life of the NVR.
To start your NVR:
1. Check the power supply is plugged into an electrical outlet. It is HIGHLY recommended that an
Uninterruptible Power Supply (UPS) be used in conjunction with the device. The Power button) on the front
panel should be red, indicating the device is receiving the power.
2. Press the POWER button on the front panel. The Power LED should turn blue. The unit will begin to start.
After the device starts up, the wizard will guide you through the initial settings, including modifying
password, date and time settings, network settings, HDD initializing, and recording.

HIKVISION 7604NI-K1B Specifications

General

Model	7604NI-K1B
HDMI Output Resolution	4K (3840 × 2160)
VGA Output Resolution	1920 × 1080
Decoding Format	H.265+/H.265/H.264+/H.264
Video Compression	H.265+/H.265/H.264+/H.264
Max Incoming Bandwidth	40 Mbps
HDD Bays	1
Storage Interface	SATA
Max HDD Capacity	6TB
Max Storage Capacity	6TB
USB Interface	2 × USB 2.0
Power Supply	12 VDC, 1.5 A
Consumption	≤ 10 W (without HDD)
Operating Humidity	10% to 90%
Synchronous Playback	4-ch
Type	NVR
Channel Capacity	4
Network Protocol	TCP/IP, DHCP, DNS, DDNS, NTP, UPnP
Network Interface	1 × RJ-45 10/100/1000 Mbps
Working Temperature	-10°C to +55°C (14°F to 131°F)
Operating Temperature	-10°C to +55°C (14°F to 131°F)
Video Output	1 × VGA, 1 × HDMI
