Chapter 2 Installation
Connect Cables to Device
Identify Cables
Identify the function of each cable before connection.
Main Bundle Definition
1
2
3
4
5
6
Cable Definition
No.
Color
Definition
1
Yellow
ACC Signal Cable
2
Black
Ground
3
Red
Power Cord
4
Black
Alarm Buttons
5
6
Black
Connects to Device Power Interface
