HIKVISION AE-DI5042-G4 User Manual

G4 Mobile Recorder• Installation Guide and Platform Settings
16
Steps:
Install the rear row camera on the interior vehicle roof.
Before installation, feed the cable through the baffle.
Run the cable along the right side of the vehicle. The cable runs from the G4 device, along
the A pillar and B pillar, to the sunroof or the dome light.
Install Rear Row Camera
Run the app, switch to Channel 4, and rotate the lens to adjust surveillance angle to make
sure the live view image can completely cover the rear passenger seat.
Fix the camera on the interior roof with screws.
Rear Row Camera Image Surveillance Image

HIKVISION AE-DI5042-G4 Specifications

General

Product color	Black
GPS (satellite)	Yes
Number of cameras	1
Main camera sensor	CMOS
Maximum frame rate	25 fps
Supported video modes	1080p
Main camera resolution	1920 x 1080 pixels
Main camera sensor size	1/2.5 \
Wi-Fi frequency	2.4 GHz
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Built-in display	No
Image formats supported	JPEG
Package depth	153 mm
Package width	223 mm
Package height	63 mm
Package weight	600 g
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Depth	82 mm
Width	124 mm
Height	33 mm
Weight	300 g
