HIKVISION DS-2CD2443G0-I User Manual

Network Cube Camera·Quick Start Guide
8
● Please make sure that the plug is firmly connected to the power
socket. When the product is mounted on wall or ceiling, the
device shall be firmly fixed.
● If smoke, odor or noise rise from the device, turn off the power
at once and unplug the power cable, and then please contact
the service center.
Cautions
● CAUTION: Hot parts! Burned fingers when handling the parts.
Wait one-half hour after switching off before
handling parts. This sticker is to indicate that the
marked item can be hot and should not be
touched without taking care. For device with this sticker, this
device is intended for installation in a restricted access location,
access can only be gained by service persons or by users who
have been instructed about the reasons for the restrictions
applied to the location and about any precautions that shall be
taken.
● Make sure the power supply voltage is correct before using the
camera.
● Do not drop the camera or subject it to physical shock.
● Do not touch sensor modules with fingers. If cleaning is
necessary, use clean cloth with a bit of ethanol and wipe it
gently. If the camera will not be used for an extended period,
please replace the lens cap to protect the sensor from dirt.

HIKVISION DS-2CD2443G0-I Specifications

General

Number of lenses	1
Fixed focal length	2.8 mm
Maximum aperture number	1.6
Minimum aperture number	1.2
Noise reduction	Yes
Total megapixels	4 MP
Gain control type	Auto
Maximum resolution	2688 x 1520 pixels
Image quality adjustment	Brightness, Contrast, Saturation, Sharpness
Video compression formats	H.264, H.264+, H.265, H.265+, M-JPEG
Noise reduction technology	3D noise reduction
Supported graphics resolutions	320 x 240, 352 x 240, 352 x 288, 640 x 360, 640 x 480 (VGA), 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2304 x 1296, 2560 x 1440, 2688 x 1520
Sensor type	CMOS
Optical sensor size	1/3 \
Pan range	0 - 360 °
Tilt angle range	0 - 90 °
Angle of rotation	360 °
Camera shutter speed	1/3 - 1/100000 s
Minimum illumination	0 lx
Type	IP security camera
Placement supported	Indoor
Connectivity technology	Wired
Built-in HDD	No
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC
Maximum memory card size	128 GB
Alert notification type	E-mail
Intelligent Video Surveillance (IVS) system features	Face detection
Number of users	32 user(s)
User access level	Administrator, Operator, User
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.1x, IEEE 802.3af
Ethernet interface type	Fast Ethernet
Supported network protocols	TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS
Sample rate	48 kHz
Voice codecs	G.711alaw, G.711ulaw, G.722.1, G.726, MP2L2, PCM
Behavior analysis	Intrusion detection, Line crossing detection
Operating temperature (T-T)	-10 - 40 °C
Operating relative humidity (H-H)	0 - 95 %
DC output current	0.5 A
DC output voltage	12
Power source type	DC, PoE
Power consumption (max)	6 W
Power consumption (Power over Ethernet (PoE))	7 W
LED type	IR
Infra-red wavelength	850 nm
Night vision distance	10 m
Form factor	Cube
Mounting type	Desk
Product color	Black, White
Housing material	Plastic

Weight and Dimensions

Depth	32.6 mm
Width	65.2 mm
Height	102.8 mm
Weight	128 g
