HIKVISION DS-2CD2443G0-I User Manual

Network Cube Camera·Quick Start Guide
31
Activating the Camera
You are required to activate the camera first by setting a strong
password for it before you can use the camera.
Activation via Web Browser, Activation via SADP, and Activation via
Client Software are all supported. We will take activation via SADP
software and Activation via Web Browser as examples to introduce
the camera activation.
Note:
Refer to the User Manual of Network Camera for Activation via
Client Software.
Activation via Web Browser
Steps:
1. Power on the camera. Connect the camera to your computer or
the switch/router which your computer connects to.
2. Input the IP address into the address bar of the web browser, and
press Enter to enter the activation interface.
Notes:
 The default IP address of the camera is 192.168.1.64.
 The computer and the camera should belong to the same
subnet.
 For the camera enables the DHCP by default, you need to use
the SADP software to search the IP address.

HIKVISION DS-2CD2443G0-I Specifications

General

Number of lenses	1
Fixed focal length	2.8 mm
Maximum aperture number	1.6
Minimum aperture number	1.2
Noise reduction	Yes
Total megapixels	4 MP
Gain control type	Auto
Maximum resolution	2688 x 1520 pixels
Image quality adjustment	Brightness, Contrast, Saturation, Sharpness
Video compression formats	H.264, H.264+, H.265, H.265+, M-JPEG
Noise reduction technology	3D noise reduction
Supported graphics resolutions	320 x 240, 352 x 240, 352 x 288, 640 x 360, 640 x 480 (VGA), 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2304 x 1296, 2560 x 1440, 2688 x 1520
Sensor type	CMOS
Optical sensor size	1/3 \
Pan range	0 - 360 °
Tilt angle range	0 - 90 °
Angle of rotation	360 °
Camera shutter speed	1/3 - 1/100000 s
Minimum illumination	0 lx
Type	IP security camera
Placement supported	Indoor
Connectivity technology	Wired
Built-in HDD	No
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC
Maximum memory card size	128 GB
Alert notification type	E-mail
Intelligent Video Surveillance (IVS) system features	Face detection
Number of users	32 user(s)
User access level	Administrator, Operator, User
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.1x, IEEE 802.3af
Ethernet interface type	Fast Ethernet
Supported network protocols	TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS
Sample rate	48 kHz
Voice codecs	G.711alaw, G.711ulaw, G.722.1, G.726, MP2L2, PCM
Behavior analysis	Intrusion detection, Line crossing detection
Operating temperature (T-T)	-10 - 40 °C
Operating relative humidity (H-H)	0 - 95 %
DC output current	0.5 A
DC output voltage	12
Power source type	DC, PoE
Power consumption (max)	6 W
Power consumption (Power over Ethernet (PoE))	7 W
LED type	IR
Infra-red wavelength	850 nm
Night vision distance	10 m
Form factor	Cube
Mounting type	Desk
Product color	Black, White
Housing material	Plastic

Weight and Dimensions

Depth	32.6 mm
Width	65.2 mm
Height	102.8 mm
Weight	128 g
