HIKVISION DS-2CD2520F User Manual

Network Mini Dome Camera·Quick Start Guide
18
18
3-Axis Adjustment Figure 2-5
10. Tighten the hex screw to fix the well-adjusted surveillance angle.
11. Align the front cover to the dome drive and tighten the set
screws on the front cover.
Install the Front Cover Figure 2-6
12. Tear off the protection film softly to complete the installation.
Adjusting Tool
Rotation
Tilt
Pan

HIKVISION DS-2CD2520F Specifications

General

Brand	HIKVISION
Model	DS-2CD2520F
Category	Security Camera
Language	English
