HIKVISION DS-2CD2942F-W Quick Start Guide

Network Fisheye Camera·Quick Start Guide
26
26
Top of Bracket
Camera
Wall
Secure the Camera Figure 2-18
3. Loosen the knob on the bracket and adjust the camera body to get
the desired surveillance angle. Tighten the knob on bracket to
secure the camera.
Tilt
Knob on Bracket
Pan
Adjust the Angle Figure 2-19
4. To install the water-proof jacket for network interface (optional),
refer to the Step 7 in Section 2.1.

HIKVISION DS-2CD2942F-W Specifications

General

Brand	HIKVISION
Model	DS-2CD2942F-W
Category	Security Camera
Language	English
