HIKVISION DS-2CD2955FWD-I User Manual

Network Fisheye Camera·Quick Start Guide
9
Cet équipement doit être installé et utilisé à une distance minimale
de 20 cm entre le radiateur et votre corps.
Safety Instruction
These instructions are intended to ensure that user can use the
product correctly to avoid danger or property loss.
The precaution measure is divided into “Warnings” and “Cautions”
Warnings: Serious injury or death may occur if any of the warnings
are neglected.
Cautions: Injury or equipment damage may occur if any of the
cautions are neglected.
Warnings
● Proper configuration of all passwords and other security
settings is the responsibility of the installer and/or end-user.
Warnings
Cautions
Warnings Follow these
safeguards to prevent
serious injury or death.
Cautions Follow these
precautions to prevent
potential injury or material
damage.

HIKVISION DS-2CD2955FWD-I Specifications

General

Type	IP security camera
Certification	CE, FCC
Placement supported	Indoor
Connectivity technology	Wired
Wide Dynamic Range (WDR)	Yes
Wi-Fi	No
Number of users	32 user(s)
Networking standards	IEEE 802.1x, IEEE 802.3af
Ethernet interface type	Fast Ethernet
Supported network protocols	TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC
Maximum memory card size	128 GB
Form factor	Dome
Mounting type	Ceiling/wall
Product color	White
Ethernet LAN (RJ-45) ports	1
Camera shutter speed	1/3 - 1/100000 s
Minimum illumination	0 lx
Field of view (FOV) angle	180 °
Sensor type	CMOS
Optical sensor size	1/2.5 \
Fixed focal length	1.05 mm
Maximum aperture number	2.2
DC output current	0.5 A
DC output voltage	12
Power source type	DC, PoE
Power consumption (max)	5 W
Power consumption (Power over Ethernet (PoE))	7.5 W
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	0 - 95 %
LED type	IR
Infra-red wavelength	850 nm
Night vision distance	8 m
Total megapixels	5 MP
Maximum resolution	2560 x 1920 pixels
Supported video modes	240p, 576p, 960p
Image quality adjustment	Brightness, Contrast, Saturation, Sharpness
Video compression formats	H.264, H.264+, H.265, H.265+, M-JPEG
Noise reduction technology	3D noise reduction
Supported graphics resolutions	352 x 240, 704 x 576, 1280 x 960, 2048 x 1536 (QXGA), 2560 x 1920
Lens mount interface	M12
Harmonized System (HS) code	85258900

Weight and Dimensions

Height	41.2 mm
Weight	600 g
Diameter	119.9 mm
