Network Camera User Manual
26
Chapter 4 Wi-Fi Settings
Purpose:
By connecting to the wireless network, you don’t need to use cable of any kind for
network connection, which is very convenient for the actual surveillance application.
Note: This chapter is only applicable for the cameras with the built-in Wi-Fi module.
Configuring Wi-Fi Connection in Manage and
Ad-hoc Modes
Purpose:
Two connection modes are supported. Choose a mode as desired and perform the
steps to configure the Wi-Fi.
Wireless Connection in Manage Mode
Steps:
1. Enter the Wi-Fi configuration interface.
Configuration> Network> Advanced Settings> Wi-Fi
2. Click Search to search the online wireless connections.
Wi-Fi List

HIKVISION DS-2CD7126G0-IZS-B Specifications

General

Model	DS-2CD7126G0-IZS-B
Type	Network Camera
Image Sensor	1/2.8" Progressive Scan CMOS
Max Resolution	1920 × 1080
IR Range	Up to 30 m
Day/Night	ICR
Video Compression	H.265+/H.265/H.264+/H.264
Bit Rate	32 Kbps to 16 Mbps
Ingress Protection	IP67
Sensor Type	CMOS
Lens Type	Varifocal
Lens	Motorized zoom lens
Focal Length	2.8 mm to 12 mm
Minimum Illumination	0 Lux with IR
Network Interface	RJ45 (10/100Base-T)
Power Supply	DC12V ± 25%, PoE (802.3af)
Power Consumption	Max 10 W
Operating Conditions	-30 °C to 60 °C (-22 °F to 140 °F), humidity: 95% or less (non-condensing)
Resolution	1920 x 1080
