User Manual of Digital Video Recorder
57
Figure 5. 8 Edit Schedule- Set Time Period
Note: Up to 8 periods can be configured for each day. And the time periods can’t be overlapped each other.
Repeat the above steps 1)-3) to schedule recording for other days in the week. If the schedule can also be set to
other days, click Copy.
Figure 5. 9 Copy Schedule to Other Days
Note: The Holiday option is available when you enable holiday schedule in Holiday settings. See
Chapter 5.6 Configuring Holiday Record.
5) Click OK to save setting and back to upper level menu.
Draw the schedule
1) Click on the color icon to select a record type in the event list on the right-side of the interface.
Figure 5. 10 Draw the Schedule
Descriptions of the color icons are shown in the figure below.
Figure 5. 11 Descriptions of the Color Icons
To Next Page
