Pan Position:
0° to 355°
Rotation Position:
0° to 355°
Tilt Position:
0° to 75°
Type III Camera
Pan Position:
0 ° to 355 °
Tilt Position:
0 ° to 75 °
Rotation Position:
0 ° to 355 °
Type IV Camera
Figure 2. 12 3-axis Adjustment
9. Fit the black liner back to the camera and tighten the
bubble of the dome camera to finish the installation.
Figure 2. 13 Finish the Installation
Menu Description
Purpose:
Call the menu by clicking button on the PTZ Control
interface, or call the preset No.95.
Steps:
1. Connect the camera with the TVI DVR, and the
monitor, shown as the figure 3-1.
Figure 3. 1 Connection
2. Power on the analog camera, TVI DVR, and the
monitor to view the image on the monitor.
3. Click PTZ Control to enter the PTZ Control interface.
