Figure 1-19 SD Card Slot
3. Secure the bracket to the wall with four screws. For details, see step 6 in the section 1.1.1
Installing the Type I Speed Dome.
Figure 1-20 Install the Bracket
4. Install the speed dome to the bracket.
1) Hang the safety rope to the speed dome and the hook on the bracket as shown in Figure
1-21.
2) Route the cables of the speed dome through the bracket.
3) Connect the corresponding cables. For the detailed information, please refer to section
1.1.5 Connecting the Cables.
