Network Speed Dome Installation Manual
8
Pendant Adapter
Lock Screw
Figure 1-17 Pendent Adapter
1.1.3 Installing the Type III Speed Dome
Steps:
1. Remove the protective sticker as shown in Figure 1-18.
Protective Sticker
Figure 1-18 Protective Sticker
2. Remove the cover on the back of the speed dome as shown in Figure 1-19. Insert the SD card
to the SD card slot and install the cover back.
