Network Speed Dome User Manual
130
the following figure.
PowerPower
Power supply board
Power supply board
Video cable
Control line
Cement pole/wall
Display
Operating center
Keyboard
DVR
UPS
GND
GND
GND
GND
1.5m underground
Figure A.3.2 Grounding in Cement Pole/Wall Installation
