Network Speed Dome User Manual
click the button to manually activate the movement, or lock
the movement when the button turns to by clicking it.
Figure 5-26 Configuring Line
5. Draw area.
(1) Click to draw a line on the image.
(2) Click the line to switch to the editing mode.
Click and drag an end to the desired place to adjust the length and angle of
the line. And click and drag the line to adjust the location.
Up to four lines are supported.
6. Configure the parameters for each defense region separately.
Direction: Select the detection direction in the dropdown list, there are A<->B,
A->B and B->A selectable.
Sensitivity: Range [1-100]. The value of the sensitivity defines the size of the
object which can trigger the alarm, when the sensitivity is high, a very small
object can trigger the alarm.
Detection Target: You can select human, vehicle, or all (human &vehicle) as
