© Hikvision
4. Edit a preset name by double clicking on the default name such as preset 1. (The pre-defined
presets are named already but not configurable. Refer to the user manual for detailed
function description.)
5. You can click to delete the preset.
Note:
You can configure up to 272 presets.
Calling a Preset:
In the PTZ control panel, select a defined preset from the list and click to call the preset.
Figure 4-7 Calling a Preset
For convenient preset selection, refer to the following steps to navigate to the preset you want.
Steps:
1. Select any preset from the list.
2. Click the preset number you need on the keyboard.
Notes:
The following presets are predefined with special commands. You can only call them but not
configure them. For instance, preset 99 is the “Start auto scan”. If you call the preset 99, the
camera starts auto scan function.
Pattern function varies depending on different camera models.
Table 4-5 Special Presets
To Next Page
